What’s different of glass door from Advanced Refrigeration Technology (II)

Wide and super clear view (Glass Door-2)

To give a large clear view of glass door, except for using Super Sapcer to keep no fog in the internal of IG unit (as mentioned in the previous article), the second key factor is to keep there is no condensation on out surface of glass door. To achieve this, we use superior quality anti-fog film, meanwhile heating the glass and door frame.

When operating, the temperature difference is quite big between cabinet inside and outside.

We keep glass door out surface clear throw heating the outer glass, keeping its temperature at about 25°C, water in air will not condense on.

But for glass door inner surface  , this method waste energy and does not really work. Door’s inner surface is usually at same low temperature with cabinet working temperature, and when door opend, it facing an instant temperature differenc, an exellent anti-fog film will be an usful choice. We choose anti-fog PET Film from USA which guarantee us an always clear view under all different conditions.

Films provide permanent anti-fog solutions, superior abrasion resistance, exceptional clarity and consistency. These films prevent fogging under all extreme temperature and humidity conditions, even after repeated cleaning or water immersion and are not affected by ammonia, alcohols, commercial glass cleaners, detergents or brief exposure to most industrial solvents such as acetone, toluene or trichloroethylene.

All those choices and design on details guarantee there is no fog on glass and frame, which finnally lead to a wide and super clear view.
